Spiral Paper Making Machine
Spiral Paper Tube Machines (Pneumatic Cut)
The High Speed Cutting Machine is specifically designed to cut board, plastics, aluminum, PVC film, wood veneers, asbestos board, emery cloth, rubber, leather, and other sheet materials with precision and speed. The Friends Makes 115 EMC, High Speed Cutting Machine is a high performance machine designed for paper mills, offset printers, print shops, book binders, copier paper industry, and stationary industry.
Salient Features Programmes
The storage capacity is 99 programmes, and each programme can store up to 99 cuts. Accuracy: 0.01 mm / 0.001 inch. Conversion between mm and inch is possible. The programme controls the back-gauge with double speed. A 1:6 ratio motor ensures accurate clutch brake system performance.
Back Gauge Accuracy
Control through upper moving system Perfecta (Seypa) Type. The screw runs on ball bearings, and the back-gauge guide moves on a ground pillar.
Drive Gear Box
Worm gear drive with ground worm needs less power than conventional drives. The gears run in an oil bath for durability.
Air Cushion Table
Facilitates easy movement of paper stacks.
Hydraulic Clamp
- Advanced design with double clamping pressure.
- Gentle clamp setting for delicate paper stacks.
- Adjustable pressure with a conveniently placed knob under the table.
Indication Light
A beam of light projects across the knife width, ensuring precise alignment before cutting.
Knife Changing Device
Knife replacement is simple and safe, handled by a single operator using a lift system.
Photo Electric Safety Guard
Infrared light beams projected above the cutting zone prevent accidents.
| Technical Data | Specification |
|---|---|
| Number of Programmes | 99 |
| Max Stop Number | 99 |
| Measuring System | Millimeters / Inches |
| Cutting Width | 115 cm (45¼") |
| Clamp Opening | 14 cm (5½") |
| Smallest Remainder Strip | 1.5 cm (0.5") |
| Deep Depth | 115 cm (45¼") |
| Power Required | 5 H.P (Main Drive) |
| Back Gauge Drive | 1 H.P. |
| Air Blower | 1 H.P. |
| Front Table Length | ½" |
| Clamp Pressure (Min.) | 100 |
| Maximum Pressure | 3700 |
| Table Height | 33" |
| Capacity Cuts per Minute | 42 |
Semi Automatic Paper Cutting Machine
Salient Features
- Friction clutch system for efficiency & low maintenance.
- Hand clamp & foot clamp for smooth operation.
- Easy knife replacement with fine height adjustment.
- Adjustable back gauge with locking system for precision.
- Compact design with centralised lubrication.
| Technical Data | 33" | 36" | 43" |
|---|---|---|---|
| Machine Size | 33" | 36" | 43" |
| Length of Cut | 33" | 36" | 43" |
| Width of Cut | 33" | 36" | 43" |
| Pile Cut | 4" | 4.5" | 5" |
| Cuts per Minute | 32 | 28 | 25 |
| Power Required (H.P.) | 2* | 2 | 5 |
| Approx. Weight (Kg.) | 1600 | 1800 | 2000 |
